Piper TURBO ARROW III User Manual

2I19
TABLE XI-V. ELECTRICAL SYSTEM TROUBLESHOOTING (cont)
Output circuit defective. Short circuit in output Disconnect wiring at
circuit. battery post of alternator.
Turn on master switch.
Disconnect each leg of
output circuit, working
from the alternator towards
the bus bar. Replace
component or wire which
was isolated as defective.
(See schematic.)
Battery installed with Remove battery and
reversed polarity. reinstall with correct
polarity.
Battery charged Remove battery. Connect
backwards. load such as landing light
lamp or similar load and
discharge battery. Recharge
with correct polarity and
test each cell for signs of
damage due to reversed
charging.
NOTE
This type of condition can
only occur in a case where
a discharged battery has
been removed from the
airplane and put on a
charger with the polarity
reversed. This reversal in
polarity cannot occur in
the airplane due to any
fault in the alternator
system.
Trouble Cause Remedy
Revised: 2/13/89
CHEROKEE ARROW III SERVICE MANUAL
ELECTRICAL SYSTEM
ALTERNATOR (cont)

Piper TURBO ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	Turbo Arrow III
Horsepower	200 hp
Max Takeoff Weight	2, 900 lbs
Fuel Capacity	72 gallons
Service Ceiling	20, 000 ft
Seating Capacity	4
Type	Single-engine piston
Propeller	Constant-speed
Landing Distance	1, 200 ft
