TABLE XI-V. ELECTRICAL SYSTEM TROUBLESHOOTING (cont)
Motor fails to operate. Low battery charge. Check and recharge if
necessary.
Defective or improper Refer to electrical wiring
wiring or loose diagram and check all
connections. wiring.
Defective starter solenoid Replace faulty unit.
or control switch.
Binding, worn, or Brushes should be a free
improperly seated fit in the brush boxes
brush or brushes with without excessive side
excessive side play. play. Binding brushes
and brush boxes should
be wiped clean with a
gasoline (undoped)
moistened cloth. A new
brush should be run in
until at least 50 percent
seated; however, if
facilities are not available
for running in brushes, then
the brush should be properly
seated by inserting a strip
of number 000 sandpaper
between the brush and
commutator, with the
sanded side next to the
brush. Pull sandpaper in
the direction of rotation,
being careful to keep it in
the same contour as the
commutator.
Trouble Cause Remedy
Revised: 2/13/89
CHEROKEE ARROW III SERVICE MANUAL
ELECTRICAL SYSTEM
STARTER
