TABLE XIV-V. BLOWER SYSTEM WIRE COLOR CODES
AIRCRAFT
MOTOR WIRES WIRES
15920 01 E362Q F0018a75FA
Pin General Singer Leece- Aircraft Pin
Nos. Industries Controls Neville Harness Nos.
See Note 2
Ground 2 Brown Brown Black AC26A 2
Low Speed 1 Red Yellow Yellow Black 1
Medium Speed 2 Black Red Red White 2
High Speed 1 Yellow Orange Orange Red 1
NOTE
1. Pin number 1 is at the pointed side of the plug and receptacle.
2. YY15062 ESB-Universal Elect. Co. Motor Wire Colors Same as E362Q
Singer Controls.
Revised: 2/13/89
3B23
CHEROKEE ARROW III SERVICE MANUAL
ACCESSORIES AND UTILITIES

Piper TURBO ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	Turbo Arrow III
Horsepower	200 hp
Max Takeoff Weight	2, 900 lbs
Fuel Capacity	72 gallons
Service Ceiling	20, 000 ft
Seating Capacity	4
Type	Single-engine piston
Propeller	Constant-speed
Landing Distance	1, 200 ft
