User Manual of WDAP-C1750
-89-
6.4.3.1. External RADIUS Server
Figure 6-18 NMS Settings—External RADIUS Server
Object Description
Name
Enter a name for the RADIUS Server.
Description
Enter a description of the RADIUS Server for reference.
RADIUS Server
Enter the RADIUS server host IP address.
Authentication Port
Set the UDP port used in the authentication protocol of the
RADIUS server. Value must be 1 to 65535.
Shared Secret
Enter a shared secret/password between 1 and 99 characters in
length.
Session Timeout
Set duration of session timeout in seconds between 0 and 86400.
Accounting
Enable or disable RADIUS accounting.
Accounting Port
When accounting is enabled (above), set the UDP port used in the
accounting protocol of the RADIUS server. Value must be between
1 and 65535.
