27 Help and error messages
27.1 Overview
The dental unit displays two types of safety messages: help messages and
error messages.
Help messages provide helpful information for the user. They are displayed,
for example, if you are using the unit or instrument incorrectly, or if the
function is not allowed for some reason. The help message disappears
automatically when the situation is corrected.
Error messages warn of a fault in the dental unit and require actions from the
user. To correct the error situation, and thus to close the error message,
follow the instructions in the message.
27.2 Help messages in short form
NOTE
The WCS related help messages can be disabled. Contact your Planmeca
dealer.
Help messages
HELP
CODE
MEANING ACTION OR EXPLANATION
H 1 Amalgam collector is 95% full. Replace or empty the collector as soon as
possible, or at least before the next patient.
Pressing the program button allows to
continue the operation until the collector is
100% (totally) full.
H 2 Amalgam collector is 100% full. Replace or empty the collector immediately.
The suction system cannot be used before
the collector is emptied or replaced.
H 3 Patient chair cannot be driven down
because safety switch is activated.
Check that the space under the seat is free
and nothing is touching the plate at the
bottom. The chair can be driven normally
after the possible obstruction has been
removed.
H 4 This left-hand instrument position allows
only syringe.
The leftmost position in the console is
reserved for the syringe only. Replace this
instrument with a syringe. Place the other
instrument to one of the four right-hand
places.
H 5 This instrument position does not accept
syringe.
Remove the syringe from this position and
replace it with any other kind of instrument.
The syringe must be placed in the leftmost
place.
H 6 Patient chair cannot be driven when
instrument is in use.
Stop the instrument (release the foot control
pedal) to be able to run the chair.
H 7 Patient chair up/down movement is not
allowed when cuspidor door is open.
Close the cuspidor door to be able to run
the chair up/down or to a pre-programmed
position.
27 Help and error messages
User's manual Planmeca Compact i 141
