Wide pedal: You can temporarily activate the manual chip blow by pushing
and holding the pedal to the right.
The flow of air will continue until you remove your foot from the pedal.
NOTE
The type of manual chip blow does not depend on the type of the automatic
chip blow, but is always dry. The manual chip blow can be set to be
dependent on programming; contact your Planmeca dealer.
20.2.7 Instrument light
The instrument light is either on or off when you pick up the instrument from
the instrument console.
Whether the light is on or off, as well as its intensity, can be defined in the
programming mode, see section "Instrument light" on page 100.
20.3 Bien-Air MCX micromotor
Besides the basic micromotor functions, the Bien-Air MCX micromotor has
some additional features. These are described below.
20.3.1 Torque limit
The torque limit is disabled by default.
Press Reverse for 4 seconds to toggle between the torque limits 25% > 50%
> 75% > 100% (torque limit disabled).
The torque limit is shown on the display as, for example, t 75 (75% of the
maximum torque limit). If the rpm limit is also selected, it is shown on the
display alternating with the torque value.
The following table presents a conversion table of percentage values to Ncm
values for a 1:1 handpiece. The tolerance is +/- 5%.
NOTE
The torque depends on the handpiece type.
Conversion table: % to Ncm (1:1 handpiece)
Percent Ncm
25 0.6
50 1.3
75 1.9
100 2.5
20 Operating instruments
80 Planmeca Compact i User's manual
