8.1.2 Over-the-patient delivery with hanging-tube instruments
1. Monitor 7. Control panel
2. Cup fill tube 8. Instrument console with hanging-tube (HT)
instruments
3. Bowl rinse tube 9. Tray
4. Bowl 10. OP delivery arm
5. Chair-mounted left-right suction arm with
Flexy-holder
11. Operating light
6. Patient chair
8.2 Detachable parts
The following detachable components are marked with a manufacturer
trademark. Do not perform dental treatment when either or both of these are
detached.
8 Planmeca Compact i dental unit
16 Planmeca Compact i User's manual
