During programming, the indicator light on the instrument button indicates
whether the function is selected to the active instrument. The setting to be
changed is shown on the small display on the control panel.
The indicator light on the Rinsing position button shows when the chair is in
the rinsing position.
The indicator light on the Program button shows when the unit is in the
programming mode.
In case of malfunction, an error code or a help message is displayed, see
section "Help and error messages" on page 141.
13.2 Control panel on Flexy-holder
The control panel on the Flexy-holder is used for controlling the dental unit
and the chair.
1. Chair buttons
2. Unit buttons
3. Flexy button
The function behind the Flexy button can be programmed by the service
technician. Depending on what has been programmed, you can do one of
the following by pressing the Flexy button:
• activate/deactivate the intraoral camera
• drive the chair to the rinsing position (default)
• turn the suction on/off
• turn the operating light’s composite mode on/off (short press) or adjust
its intensity (long press)
• change the light tone of the operating light
For more information, contact your Planmeca dealer.
13 Control panel
52 Planmeca Compact i User's manual
