General error messages
ERROR
CODE
EXPLANATION
E2.03 Bowl rinse valve open circuit.
Error can be detected when circuit is dead.
E2.04 Cup filling valve open circuit.
Error can be detected when circuit is dead.
E2.05 Main Control PCB output open circuit warning.
E2.06 Separator pulse valve open circuit.
Error can be detected when circuit is dead.
E2.07 Main Control PCB output open circuit warning.
E2.08 Main Control PCB output open circuit warning.
E2.09 Main Control PCB output open circuit warning.
E2.10 Main Control PCB output open circuit warning.
E2.11 Separator start signal open circuit / Microvac valve open
circuit.
E2.12 Assistant syringe water valve open circuit.
Error can be detected when circuit is dead.
E2.13 Separator alarm reset signal open circuit.
Error can be detected when circuit is dead.
E2.14 Main Control PCB output open circuit warning.
E2.15 Not used or not in the manuals.
E3.1 Incoming air pressure compared to water pressure is too low.
Ensure that air pressure main switch is on. If problem persists,
contact service.
E3.2 Internal water pressure too low.
Check dental unit's incoming water pressure. Ensure that
dental unit inlet water tap is open.
E3.4 Internal air pressure (after regulator) is too low.
Ensure that air pressure main switch is on. If problem persists,
contact service.
E3.5 Internal air pressure (after pres. regulator) is too high.
Check pressure regulator, pressure sensor and pressure
block connector.
E3.6 Waterline cleaning feed pressure too low.
Check and adjust waterline cleaning feed pressure. Replace
waterline cleaning feed regulator if problem still exists.
E3.7 Waterline cleaning flush pressure too low.
Check dental unit's incoming water pressure. Ensure that
dental unit inlet water tap is open.
E4.1 Short circuit in cable from MCB to control panel / suction
holder in branch 1.
27 Help and error messages
User's manual Planmeca Compact i 151
