Planmeca Compact i Classic v2 - Centre Knob Functions; Left-side and Right-side Knob Functions; Pedal Functions

Micromotor, turbine
Action Function
Pedal down, long activation Manual chip blow; activated for as long as the pedal is
pushed and held down
Scaler
Action Function
Pedal left / pedal right Drive instrument
Pedal down, short activation Change spray on / off
Unit controlled polymerisation light
Action Function
Pedal left / pedal right / pedal down Start / stop instrument
Intraoral camera
Action Function
Pedal left / pedal right Freeze / unfreeze picture
Pedal down Save still picture
Intraoral scanner
Action Function
Pedal left Move upward in the list of scan type selection tools
Pedal right Move downward in the list of scan type selection tools
Pedal down, short activation Start scanning
Pedal down, long activation Take image
14 Foot control
56 Planmeca Compact i User's manual
