ProMax X-ray unit with Dimax3 TOC - 5
TABLE OF CONTENTS
Technical Manual
1.8 Cephalostat head support position adjustment.........................................H-15
1.9 Calibrating the C-arm position ..................................................................H-18
1.10 Synchronizing the scanning mechanism and first primary collimator .......H-21
1.11 Adjusting the cephalometric beam vertical position ..................................H-23
1.12 Checking the second primary collimator position......................................H-26
1.13 Adjusting the second primary collimator position......................................H-29
1.14 Beam Check .............................................................................................H-33
1.15 Calibrating the cephalostat sensor head...................................................H-38
1.16 Calibrating the Cephalometric DEC ..........................................................H-46
1.17 Checking the adjustment ..........................................................................H-52
2 REMOVING AND ATTACHING THE SECOND PRIMARY COLLIMATOR H-53
2.1 Attaching the second primary collimator covers .......................................H-54
3 DETACHING AND ATTACHING THE SENSOR HEAD............................. H-55
3.1 Cephalostat with movable sensor head ....................................................H-55
3.2 Cephalostat with fixed sensor head - removing and attaching the
sensor head ..............................................................................................H-59
4 REMOVING THE HOUSINGS AND COVERS.......................................... H-62
4.1 Removing the housings of the head support ............................................H-62
5 REPLACING PCBS ................................................................................. H-65
5.1 Cephalostat connector PCB......................................................................H-65
Chapter I DIAGRAMS
