10 PARTS REPLACEMENT & REPAIR
66 Planmeca ProX Technical manual
20.Attach the cables to the bracket arm with cable ties. Do not tighten the cable ties yet.
Leave the cables slightly loose in the joints but make sure that the cables do not push the
arm covers. Tighten the cable ties so that the attachment point is towards arm center.
