This command is a channel integer command. See Section 6.3 and Section 6.2 for more information
on this type of command. The minimum and maximum values for this command are 1 and 5,
respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
Example Description Status Message
Q01LAGCRATEA3
Set AGC ramp rate on input
channel A to 3 dB/sec.
Q01LAGCRATEA3
Q01LAGCRATEB?
Query the AGC ramp rate on
input channel B.
Q01LAGCRATEBx, where x is a number
between 1 and 5, depending on the current
setting of the AGC ramp rate on input channel
B.
8.60. MACROA -- Add Command to Current Macro
This command adds a command to the macro currently in progress. This is used in conjunction with
the MACROS and MACROW commands to create a new macro.
The syntax of this command specifies a macro number, a comma, and then the command to be
added to the macro. The command to be added to the macro can be any valid command except the
following:
● any PRESET command
● any MACRO command
● any logic input or output command
If an attempt to assign an invalid command to a macro is made (via
MACROA), then the error
condition ERROR#074 will be generated.
An error will be generated if the specified command is not a valid command. However, an error will
not be generated if the specified command is valid, but its data is invalid. For example:
Q01MACROA25,LAYDOWNTHEBOOGIE
Would return an error because it does not contain a valid command. However:
Q01MACROA62,MUTEOMYMOTHERINLAW
Would not return an error because it contains a
MUTEO command. An error would be returned when
the macro is executed with a
MACROX or MACROQ command and it tries to execute the MUTEO
command with strange data.
