The last byte (ä) consists of only one value.
ä = 0x84 = 132 → 132 - 132 = 0 = Idle
So, we know that the AEC on input 1 is in idle mode.
In the above description, the data in the BLDATA command consists of 10 bytes (3 input levels + 3
output levels + 1 AEC reference level + 1 room gain level + 1 AGC gain level + 1 AEC state). It is
possible to tell the EF2210 to only send a subset of this information. There are two reasons you might
want to do this. First, it makes parsing the data easier since you can ask for only the data that you
are interested in. Second, when you decrease the amount of data being sent, the EF2210 can send
the messages faster. This means that if you are trying to implement a signal level meter, you can get
faster refresh rates by asking the EF2210 to only send the data you're interested in.
Suppose you were only interested in signal levels on inputs A-B. You could send the following
command.
Q01BLINFO0110000000
In the above
BLINFO command, there are 1's in the positions of the data that we want and 0's in the
positions of the data that we don't want. Now, when we send a BLDATA? command or enable
BLAUTO, the Vortex sends messages of the form:
Q01BLDATAii
Where the ii bytes are the signal levels for inputs A-B.
8.30. BLINFO -- Select Information to be Reported in
BLDATA
This command controls which bytes are sent in the BLDATA command. See the description of the
BLDATA command for more information on the BLINFO command.
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
8.31. BROAD2 -- Broadcast Arbitrary Command Strings to
RS-232 Port
This command is used to broadcast arbitrary commands to the RS-232 port for controlling other
devices (not necessarily other Vortex devices). For example, ' ' ' ' Q01BROAD2:ATDT4048921180' '
would cause the Vortex to send out 'ATDT4048921180' via its RS-232 port. If a modem was
