DESCRIPTION OF PROGRAMMING PARAMETERS
111
Screen
Description
Default
value
Range
Function
Set
on
RUN
dr.10
Torque
control
N
N
Y
Not configurable by the user.
NO
dr.11
Inch
Frequency
10.00Hz
dr.19 to
dr.20
Set the motor inch frequency.
YES
dr.12
INCH
acceleration
time
20.0s
0.0 to
600.0s
Set the time in which the drive accelerates to
reach the maximum speed.
YES
dr.13
INCH
deceleration
time
30.0s
0.0 to
600.0s
Set the time in which the drive decelerates from
the maximum speed until stopping.
YES
dr.14
Motor power
(*)
0.2 kW
0.4 kW
…
30.0 kW
Set the motor rated power according to its
nameplate.
NO
dr.15
Torque boost
Manual
Manual
Auto1
Auto2
Proportional to the initial voltage value applied
to the motor in the start moment to overcome
the resistive torque in heavy starts.
OPT.
DESCR.
FUNCTION
0
Manual
Starting voltage manual
setting by the use of
parameters dr.16 y dr.17.
1
Auto1
The drive automatically
calculates the voltage to
apply at the start using the
motor parameters.
2
Auto2
NO
dr.16
Start torque
in forward
direction
+2.0%
0.0 to
15.0%
Set the start torque in forward direction.
NO
dr.17
Start torque
in reverse
direction
+2.0%
0.0 to
15.0%
Set the start torque in reverse direction.
NO
dr.18
Motor
frequency
60.00Hz
30.00 to
400.00H
z
Set the base frequency (drive output frequency
when running at its rated voltage) according to
the motor nameplate.
NO
(*) This value depends on the motor setting.
