DESCRIPTION OF PROGRAMMING PARAMETERS
Screen
Description
Default
value
Range
Function
Set
on
RUN
Ad.8
Stop mode
RAMP
0 to 4
Select the drive main stop mode. This value
should be adequate for each application.
OPT.
DESCR.
FUNCTION
0
RAMP
The drive will stop
applying a frequency
ramp to stop the motor.
1
DC
BRAKE
The drive will apply DC to
stop the motor. To
configure this option, see
parameters from Ad.14 to
Ad.17.
2
SPIN
The drive will cut the
motor output supply,
stopping due to inertia.
4
POW
BRKE
The drive will stop the
motor as soon as possible
by controlling the
regenerative energy to
avoid an overvoltage
fault. This option may
increase or decrease the
deceleration time
according to the inertia of
the load.
Note: Do not use this
option in applications with
frequent acceleration /
deceleration. It could
cause overheating.
NO
Ad.9
Allow speed
inversion
None
None
FWDPre
v
REVPrev
Invert motor speed. This function helps to
prevent the motor from rotating in inverse
direction.
OPT.
DESCR.
FUNCTION
0
None
The motor can spin in
both directions.
1
FWDPre
v
Motor cannot rotate
clockwise.
2
RevPrev
Motor cannot rotate anti
clockwise.
NO
