Power Electronics SD300 Series User Manual

SD300
POWER ELECTRONICS
144
DESCRIPTION OF PROGRAMMING PARAMETERS
Screen
Description
Default
value
Range
Function
Set on
RUN
Cn.24
[18]
Independent
controller
integral gain 2
(*)
1.0 to
1000.0%
Set the integral gain 2 of a separate
controller.
YES
Cn.25
[18]
Integral time
sensorless
controller
(*)
10 to
999ms
Sensorless speed controller integral gain 0.
YES
Cn.26
[18]
Flux estimator
proportional
gain
(*)
1 to
200%
Sensorless vector control requires the rotor
flux estimator. Use these parameters to
adjust flux estimator gain
YES
Cn.27
[18]
Flux estimator
integral gain
(*)
1 to
200%
YES
Cn.28
[18]
Speed
estimator
proportional
gain 1
(*)
0 to
32767
Adjusts speed estimator gain for sensorless
vector control:
• At low speed (10Hz or lower), increase
the value of Cn.29 by increments of 5.
• At mid speed (30 Hz or higher), increase
the value of Cn.28 by increments of 500.
If the parameter setting is too extreme,
over current trip may occur at low speed.
YES
Cn.29
[18]
Speed
estimator
integral gain 1
(*)
100 to
1000
YES
Cn.30
[18]
Speed
estimator
integral gain 2
(*)
100 to
10000
YES
Cn.31
[18]
Sensorless
cont.
proportional
gain
(*)
10 to
1000
Adjusts the P and I gains of the sensorless
current controller.
If the value of Cn.10 is high, an overcurrent
trip at start can occur. In this case, reduce
the value of Cn.31 by decrements of 10.
YES
Cn.32
[18]
Sensorless
cont. integral
gain
(*)
10 to
1000
YES
[18] Displayed when dr.9 is set to 4 (S-less1) and Cn.20 is set to 1 (YES).
(*) Estos valores dependen del ajuste del motor.
