DESCRIPTION OF PROGRAMMING PARAMETERS
149
Screen
Description
Default
value
Range
Function
Set on
RUN
Cn.53
Torque limit
reference
LOCAL
0 to 12
Select the source to introduce the torque
limit reference.
OPT.
DESCR.
FUNCTION
0
LOCAL
Reference will be given
by keypad and will be
set in (dr.2) – Local
Torque.
2
V1
Reference will be
introduced through the
voltage analog input 1.
4
V2
Reference will be
introduced through the
voltage analog input 2.
5
I2
Reference will be
introduced through the
current analog input 2.
6
MODBUS
The reference will be
introduced through
Modbus.
8
COMMS
The reference will be
introduced through the
communications.
9
PLC
The common area can
be linked with user
sequence output and
can be used as
command.
12
PULSE
Reference will be
introduced through the
Pulse input.
NO
Cn.54
[19]
Forward
positive torque
limit
180.0%
0.0 to
200.0%
The user can set the forward motoring
operation torque limit whenever the torque
limit reference has been set as LOCAL.
YES
[
19
] Displayed when dr.9 is set to 4 (Sless-1). This will change the initial value of Ad.74,
Torque limit, to 150%.
