Power Electronics SD300 Series User Manual

SD300
POWER ELECTRONICS
180
DESCRIPTION OF PROGRAMMING PARAMETERS
Screen
Description
Default
value
Range
Function
Set on
RUN
OU.41
Digital outputs
status
00
00 to 11
Multi-function output monitor.
OPT.
FUNCTION
00
No outputs enabled
01
Output 1 enabled
10
Output 1 enabled
11
Output 1 and 2 enabled
YES
OU.50
Digital output
connection
delay
0.00s
0.00 to
100.00s
The user can specify a delay in the digital
output 1 and relays disconnection. If during
the connection delay time the activation
condition disappears, the relay will not be
enabled.
YES
OU.51
Digital output
disconnection
delay
0.00s
0.00 to
100.00s
The user can specify a delay within the
digital output 1 and relays disconnection. If
during the disconnection delay time, the
disable condition disappears, the relay will
not be disabled.
YES
OU.52
NC/NO Relays
logic
00
00 to 11
Defines the type of contact following this
order: Digital Output 1, Relay 2 and Relay 1,
from left to right according to the bit
assignment.
OPT.
FUNCTION
0
Contact normally open (NO)
1
Contact normally closed (NC)
NO
OU.53
Digital output
connection
delay on fault
0.00s
0.00 to
100.00s
If a fault trip occurs, trip relay or multi-
function output operates after the time delay
set in OU.53. Terminal is off with the input
initialized after the time delay set in OU.54.
YES
OU.54
Digital output
disconnection
delay on fault
0.00s
0.00 to
100.00s
YES
OU.55
Digital output
connection
delay
0.00s
0.00 to
100.00s
Input a signal (On) to the timer terminal to
operate a timer output (Timer out) after the
time set at OU.55 has passed. When the
multi-function input terminal is off, multi-
function output or relay turns off after the
time set at OU.56.
See also digital inputs option 38 ‘Timer In’.
YES
OU.56
Digital output
disconnection
delay
0.00s
0.00 to
100.00s
YES
