POWER ELECTRONICS
DESCRIPTION OF PROGRAMMING PARAMETERS
217
Screen
Description
Default
value
Range
Function
Set on
RUN
Note: Comes from the previous page.
OPT.
DESCR.
FUNCTION
26
PI_
PROCES
S
A is an input error, B is
an output limit, C is the
value of Const PI output.
Range of C is 0 to 32767.
27
UP
COUNT
Upcounts the pulses and
then output the value
UPCOUNT(A, B, C).
After receiving a trigger
input (A), outputs are
upcounted by C
conditions. If the B inputs
is 1, do not operate and
display 0. If the B inputs is
0, operate.
If C is 0, upcount when A
changes from 0 to 1.
If C is 1, upcount when A
is changed from 1 to 0.
If C is 2, upcount
whenever the input at A
changes.
Output range is: 0 to
32767.
28
DOWN
COUNT
Downcounts the pulses
and then output the
value- DOWNCOUNT(A,
B, C).
After receiving a trigger
input (A), outputs are
downcounted by C
conditions. If the B input is
1, do not operate and
display the initial value of
C. If the B input is 0,
operate. Downcounts
when the A parameter
changes from 0 to 1.
