SD300
POWER ELECTRONICS
218
DESCRIPTION OF PROGRAMMING PARAMETERS
Screen
Description
Default
value
Range
Function
Set on
RUN
UF.2
Input A for
PLC function 1
0
0 to
65535
Communication address of the first input
parameter of the PLC function.
NO
UF.3
Input B for
PLC function 1
0
0 to
65535
Communication address of the second input
parameter of the PLC function.
NO
UF.4
Input C for
PLC function 1
0
0 to
65535
Communication address of the third input
parameter of the PLC function.
NO
UF.5
Output PLC
function 1
+0
-32767
to 32767
Output value (Read Only) after performing
the function block.
NO
UF.6
PLC function 2
NOP
See
UF.1
See UF.1.
NO
UF.7
Input A for
PLC function 2
0
See
UF.2
See UF.2.
NO
UF.8
Input B for
PLC function 2
0
See
UF.3
See UF.3.
NO
UF.9
Input C for
PLC function 2
0
See
UF.4
See UF.4.
NO
UF.10
Output PLC
function 2
+0
See
UF.5
See UF.5.
NO
UF.86
PLC function
18
NOP
See
UF.1
See UF.1.
NO
UF.87
Input A for
PLC function
18
0
See
UF.2
See UF.2.
NO
UF.88
Input B for
PLC function
18
0
See
UF.3
See UF.3.
NO
UF.89
Input C for
PLC function
18
0
See
UF.4
See UF.4.
NO
UF.90
Output PLC
function 18
+0
See
UF.5
See UF.5.
NO
