POWER ELECTRONICS
SD300
MODBUS COMMUNICATION
233
Modbus Address
Parameter
Scale
Units
Values
Decimal
Hexadecimal
Digital inputs
information
Bit 1: P2
Bit 2: P3
Bit 3: P4
Bit 4: P5
Bit 5: P6
Bit 6: P7
40801
0h0321
Digital outputs
information
-
-
Bit 0: Relay 1
Bit 1: Multi-function output
40802
0h0322
Communication
addresses information
-
-
Bit 0: Input 1 (CM.70)
Bit 1: Input 2 (CM.71)
Bit 2: Input 3 (CM.72)
Bit 3: Input 4 (CM.73)
Bit 4: Input 5 (CM.74)
Bit 5: Input 6 (CM.75)
Bit 6: Input 7 (CM.76)
Bit 7: Input 8 (CM.77)
40803
0h0323
Selected motor
-
-
0: Motor 1
1: Motor 2
40804
0h0324
V1
0.01
%
Analog voltage input V1
40805
0h0325
V2
0.01
%
Analog voltage input V2
40806
0h0326
I2
0.01
%
Analog current input I2
40807
0h0327
AO1
0.01
%
Analog output 1
40808
0h0328
AO2
0.01
%
Analog output 2
40813
0h032D
Drive temperature
1
ºC
-
40814
0h032E
Drive power
consumption
1
kWh
-
40815
0h032F
1
kWh
40816
0h0330
Latch type trip 1
information
-
-
Bit 0: Overload
Bit 1: Underload
Bit 2: Inverter Overload
Bit 3: E-Thermal
Bit 4: Ground Fault
Bit 5: Output open-phase
Bit 6: Input open-phase
Bit 9: NTC
Bit 10: Overcurrent
Bit 11: Overvoltage
Bit 12: External trip
Bit 13: Arm short
Bit 14: Over Heat
Bit 15: Open fuse
