MODBUS COMMUNICATION
Modbus Address
Parameter
Scale
Units
Values
Decimal
Hexadecimal
40774
0h0306
Drive operation
frequency command
source
-
-
Bit 0 – 7: Frequency command
source
0: Keypad speed
1: Keypad torque
2-4: Up/Down operation speed
5: V1, 7: V2, 8: I2, 9: Pulse
10: Built-in RS 485
11: Optional communication
card
12: PLC
13: Jog
14: PID
25-39: Multi-step speed
frequency
Bit 8-15: Operation command
source
0: Keypad
1: Optional communication
card
2: PLC
3: Built-in RS 485
4: Terminal block
40775
0h0307
SW Version
-
-
(Ex) 0x0100: Version 1.0
40776
0h0308
SW Version
-
-
(Ex) 0x0101: Version 1.1
40784
0h0310
Output current
0.1
A
-
40785
0h0311
Output frequency
0.01
Hz
-
40786
0h0312
Output rpm
0
rpm
-
40787
0h0313
Motor speed feedback
0
rpm
-32768 rpm – 32767 rpm
(directional)
40788
0h0314
Output voltage
1
V
-
40789
0h0315
DC bus voltage
1
V
-
40790
0h0316
Output power
0.1
kW
-
40791
0h0317
Output torque
0.1
%
-
40792
0h0318
PID reference
0.1
%
-
40793
0h0319
PID feedback
0.1
%
-
40794
0h031A
Motor 1 poles number
-
-
Visualization of motor 1 poles
40795
0h031B
Motor 2 poles number
-
-
Visualization of motor 2 poles
40796
0h031C
Poles number of the
selected motor
-
-
Visualization of selected motor
poles
40797
0h031D
Select Hz/rpm
-
-
0: Hz, 1: rpm
40800
0h0320
Bit 0: P1
