SD300
POWER ELECTRONICS
284
ACCESSORIES
Frame 1F:
Frame 1F flange option kit dimensions.
Model
W
H
D1
D2
A1
A2
B1
B2
B3
Ø
Weight*
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
kg
(lb)
SD300242F
SD300312F
SD300342F
106
(4.17)
220
(8.66)
130
(5.12)
38.8
(1.53)
92
(3.62)
72.5
(2.85)
211.4
(8.32)
197.8
(7,79)
97.1
(3.82)
3.5
(0.14)
1.5 (3.3)
*Total weight of the drive with the flange installed
