Power Electronics SD300 Series - Page 287

POWER ELECTRONICS
SD300
ACCESSORIES
285
Frame 2F:
Frame 2F flange option kit dimensions.
Model
W
H
D1
D2
A1
A2
B1
B2
B3
Ø
Weight*
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
kg
(lb)
SD300612F
SD300912F
SD300542F
SD300742F
140
(5.51)
220
(8.66)
140
(5.51)
52.6
(2.07)
126
(4.96)
103.1
(4.06)
209.6
(8.25)
196.2
(7.72)
84.9
(3.34)
4.5
(0.18)
2.2
(4.85)
*Total weight of the drive with the flange installed
