Power Electronics SD300 Series - Page 30

SD300
POWER ELECTRONICS
28
DIMENSIONS
Frame 5N Dimensions
INPUT VOLTAGE
PHASES
EQUIPMENT
200~240[V]
1
SD301212
200~240[V]
3
SD301822
380~480[V]
3
SD301042
DIMENSIONS [mm/inch]
WEIGHT
(kg/lb)
W1
W2
H1
H2
H3
D1
A
B
Ø
140
(5.5”)
132.2
(5.2”)
128
(5”)
120.7
(4.8”)
3.7
(0.1”)
145
(5.7”)
3.9
(0.2”)
4.4
(0.2”)
4.5
(0.2”)
2.7 (6lb)
Frame 5N dimensions
