Power Electronics SD300 Series User Manual

SD300
POWER ELECTRONICS
302
COMMONLY USED CONFIGURATIONS
Parameter
Default
value
Description
Set value
dr.97
2.x
Software version
-
Cn.4
3kHz
Modulation frequency
5kHz
AP.1
0
Application function
selection
2: PID control enabled.
AP.19
50.0
PID local
40.0 (adjust desired PID in %)
AP.20
0
Select PID regulator
source
0: PID set point introduced from keypad
AP.21
0
Select feedback signal
source
3: I2 input (Feedback from a signal of 0 – 20mA).
AP.22
50.0
PID controller
proportional gain
50.0
AP.23
10.0
PID controller
integration time
10.0
AP.24
0.0
PID controller
differential time
0.0
AP.28
0
PID mode
0: Process
1: Normal.
AP.29
60.00
Upper limit PID output
50.00Hz
AP.30
-60.00
Lower limit PID output
00.00Hz
AP.37
60 seg
Sleep mode activation
delay
40 seg (Delay time before the drive stops).
AP.38
0.00Hz
Sleep mode activation
speed
10.00Hz (Frequency to stop operating and enter
in sleep mode).
AP.39
35%
Awakening level
10% (% of the feedback to start again).
In.1
50.00Hz
Analog input max. freq
50.00Hz
In.52
10ms
I2 filter
10ms (Analogue input current filter).
In.53
4.00mA
I2 minimum current
4.00mA (I2 minimum current adjustment).
In.54
0.00
I2 minimum reference
0.00 (% of the value set In.1)
In.55
20.00mA
I2 maximum current
20.00mA (I2 maximum current adjustment)
In.56
100.00
I2 maximum reference
100.00 (% of the value set In.1)
In.65
1
Digital input 1
1: Forward start command
