Power Electronics SD300 Series User Manual

POWER ELECTRONICS
SD300
CONFIGURATION REGISTER
325
PARAMETER
DEFAULT
VALUE
SETTING 1
SETTING 2
Cn.27
Flux estimator integral gain
__%
___________________
___________________
Cn.28
Speed estimator proportional
gain 1
___
___________________
___________________
Cn.29
Speed estimator integral gain
1
___
___________________
___________________
Cn.30
Speed estimator integral gain
2
___
___________________
___________________
Cn.31
Sensorless cont. proportional
gain
___
___________________
___________________
Cn.32
Sensorless controller integral
gain
___
___________________
___________________
Cn.33
PM D-axis back-EMF
estimated gain (%)
100.0%
__________________
__________________
Cn.34
PM Q-axis back-EMF
estimated gain (%)
2
__________________
__________________
Cn.35
Initial pole position estimation
retry
20ms
__________________
__________________
Cn.36
Initial pole position estimation
interval
15%
__________________
__________________
Cn.37
Initial pole position estimation
pulse current (%)
500%
__________________
__________________
Cn.38
Initial pole position estimation
pulse voltage (%)
100.0%
__________________
__________________
Cn.39
PM dead-time range (%)
20ms
__________________
__________________
Cn.40
PM dead-time voltage (%)
100.0%
__________________
__________________
Cn.41
PM speed estimator
proportional gain
100
__________________
__________________
Cn.42
PM speed estimator integral
gain
10
__________________
__________________
Cn.43
PM speed estimator
proportional gain 2
300
__________________
__________________
