Power Electronics SD300 Series User Manual

SD300
POWER ELECTRONICS
334
CONFIGURATION REGISTER
PARAMETER
DEFAULT
VALUE
SETTING 1
SETTING 2
CM.75
Communication multifunction
input 6
None
___________________
___________________
CM.76
Communication multifunction
input 7
None
___________________
___________________
CM.77
Communication multifunction
input 8
None
___________________
___________________
CM.86
Comm. multifunction input
monitoring
0
___________________
___________________
CM.90
Data frame comm. monitor
0
___________________
___________________
CM.91
Received data frames counter
0
___________________
___________________
CM.92
Frames with error counter
0
___________________
___________________
CM.93
NAK frames
0
___________________
___________________
CM.94
Communications update
NO
___________________
___________________
CM.95
P2P communication selection
Disable all
___________________
___________________
CM.96
Digital output selection
0
___________________
___________________
AP: PID
AP.1
Application function selection
Proc PID
___________________
___________________
AP.2
Enable PLC mode
N
___________________
___________________
AP.16
PID output
+0.0%
___________________
___________________
AP.17
PID reference
+50.00%
___________________
___________________
AP.18
PID feedback
+0.00%
___________________
___________________
AP.19
PID local
+50.00%
___________________
___________________
AP.20
Select PID regulator source
MREF
___________________
___________________
