Power Electronics SD300 Series User Manual

POWER ELECTRONICS
SD300
CONFIGURATION REGISTER
335
PARAMETER
DEFAULT
VALUE
SETTING 1
SETTING 2
AP.21
Select feedback signal source
V1
___________________
___________________
AP.22
PID controller proportional
gain
+50.00%
___________________
___________________
AP.23
PID controller integration time
10.0ms
___________________
___________________
AP.24
PID controller differential time
0ms
___________________
___________________
AP.25
PID output fine adjustment
+0.0%
___________________
___________________
AP.26
Proportional gain scale
100.0%
___________________
___________________
AP.27
PID Filter
0ms
___________________
___________________
AP.28
PID mode
Process
___________________
___________________
AP.29
Upper limit PID output
+60.00Hz
___________________
___________________
AP.30
Lower limit PID output
-60.00Hz
___________________
___________________
AP.31
Invert PID
N
___________________
___________________
AP.32
PID output scale
+100.00%
___________________
___________________
AP.34
PrePID reference
0.00Hz
___________________
___________________
AP.35
PrePID end reference
0.0%
___________________
___________________
AP.36
PrePID delay
600s
___________________
___________________
AP.37
Sleep mode activation delay
60.0s
___________________
___________________
AP.38
Sleep mode activation speed
0.00Hz
___________________
___________________
AP.39
Awakening level
+35%
___________________
___________________
AP.40
PID WakeUp mode
Below
___________________
___________________
AP.42
PID unit
%
___________________
___________________
