Power Electronics SD300 Series User Manual

SD300
POWER ELECTRONICS
336
CONFIGURATION REGISTER
PARAMETER
DEFAULT
VALUE
SETTING 1
SETTING 2
AP.43
PID unit gain
100.00%
___________________
___________________
AP.44
PID scale unit
x1
___________________
___________________
AP.45
Proportional gain 2
100.0%
___________________
___________________
Pr: Protections
Pr.4
Load duty type
Heavy
___________________
___________________
Pr.5
Phase loss type
NONE
___________________
___________________
Pr.6
Ripple voltage
15V
___________________
___________________
Pr.7
Fault deceleration time
3.0s
___________________
___________________
Pr.8
Start after restart
N
___________________
___________________
Pr.9
Retry attempts number
0
___________________
___________________
Pr.10
Retry delay
1.0s
___________________
___________________
Pr.12
Response in case of a speed
reference loss
None
___________________
___________________
Pr.13
Lost reference delay
1.0s
___________________
___________________
Pr.14
Reference for lost reference
0.00Hz
___________________
___________________
Pr.15
AI Lost Level
Half
___________________
___________________
Pr.17
Overload warning select
YES
___________________
___________________
Pr.18
Overload warning level
+150%
___________________
___________________
Pr.19
Overload warning time
10.0s
___________________
___________________
Pr.20
Overload trip select
FreeRun
___________________
___________________
Pr.21
Overload level
180%
___________________
___________________
