Power Electronics SD300 Series User Manual

POWER ELECTRONICS
SD300
CONFIGURATION REGISTER
337
PARAMETER
DEFAULT
VALUE
SETTING 1
SETTING 2
Pr.22
Overload trip time
60.0s
___________________
___________________
Pr.25
Enable underload
YES
___________________
___________________
Pr.26
Underload warning delay
10.0s
___________________
___________________
Pr.27
Underload fault mode
None
___________________
___________________
Pr.28
Underload fault delay
30.0
___________________
___________________
Pr.29
Underload minimum level
+30%
___________________
___________________
Pr.30
Underload maximum level
+30%
___________________
___________________
Pr.31
Action in case no motor is
detected
None
___________________
___________________
Pr.32
No motor fault level
+5%
___________________
___________________
Pr.33
No motor fault delay
3.0s
___________________
___________________
Pr.40
Action in case of thermo-
electronic fault
None
___________________
___________________
Pr.41
Motor cooling mode at zero
speed
SELF
___________________
___________________
Pr.42
Overcurrent level during 1 min
150%
___________________
___________________
Pr.43
Continuous overcurrent level
+120%
___________________
___________________
Pr.45
Free run trip mode
FreeRun
___________________
___________________
Pr.50
Stall prevention
00
___________________
___________________
Pr.51
Speed for stall protection 1
60Hz
___________________
___________________
Pr.52
Level for stall protection 1
180%
___________________
___________________
Pr.53
Speed for stall protection 2
60Hz
___________________
___________________
