Power Electronics SD300 Series User Manual

SD300
POWER ELECTRONICS
338
CONFIGURATION REGISTER
PARAMETER
DEFAULT
VALUE
SETTING 1
SETTING 2
Pr.54
Level for stall protection 2
180%
___________________
___________________
Pr.55
Speed for stall protection 3
60Hz
___________________
___________________
Pr.56
Level for stall protection 3
180%
___________________
___________________
Pr.57
Speed for stall protection 4
60Hz
___________________
___________________
Pr.58
Level for stall protection 4
180%
___________________
___________________
Pr.59
Flux braking gain
0%
___________________
___________________
Pr.60
CAP diagnosis level
0%
___________________
___________________
Pr.61
Capacitor diagnosis mode
+0%
___________________
___________________
Pr.62
CAP exchange warning level
0%
___________________
___________________
Pr.63
Capacitance reference
0.0%
___________________
___________________
Pr.66
Braking resistor configuration
+0%
___________________
___________________
Pr.73
Speed deviation fault
N
___________________
___________________
Pr.74
Speed deviation band
50
___________________
___________________
Pr.75
Speed deviation time
60
___________________
___________________
Pr.79
Action in case of fan trip
Warn
___________________
___________________
Pr.80
Optional card trip mode
FreeRun
___________________
___________________
Pr.81
Low voltage trip delay
0.0s
___________________
___________________
Pr.82
Enable low voltage trip
YES
___________________
___________________
Pr.86
Fan use percentage
0%
___________________
___________________
Pr.87
Fan exchange warning level
90.0%
___________________
___________________
