Figure 2-13
2.1.4 Inspection of crank and connecting rod
Check that whether crank and connecting rod can rotate without
stuck and whether the clearance between crank and connecting
rod is 0.5～0.6mm.The hop of crank shaft should be 0.05mm.If
not so, replace it. See figure 2-14-1, figure 2-14-2.
Figure 2-14-1 Figure 2-14-2
