4.2.1.5 Assembly of Front Brake System

1.Use Fuel Pipe Brackets (2pcs) and Hexagon Flange

Bolts M8*16 (2pcs) to connect the Fuel Pipe Clip with

both left and right Lower Front L/R rocker arms.

Caution: Fuel Pipe must avoid physical contact

with other components in movement.

2、Fix the Disk Brake Plate onto the Front Wheel Hub

with M8 Special Bolts (4pcs) (Figure 4-2-4)

Caution: grease the bolt with thread glue when

fastening. Fastening Torque of the Bolt:

22N.m-26N.m

3、 Fix the Front Wheel Hub onto the Front Wheel Shaft

with open-groove nuts and cotter pins. (Figure 4-2-4)

Fastening Torque of Open-groove nut:

50N.m—60N.m

4、 Fix the Plate Clip onto Front Turning Joint with

M8 Bolts (4pcs)

Fastening Torque: 18 N.m--22 N.m

5、Assemble Front Wheel Components onto Front Wheel

Hub with M10 Conical Nuts of GB/T802 (4pcs) (Figure

4-2-15)
