3、Check all Fuel Pipes for deterioration, distortion,
crack, wear and other hidden defects.
4、Check the Brake Plate Clip for distortion, crack, rust
and stuck.
5、Inspect the Disk Brake Shoe for wear condition. Brake
shoe must be replaced when worn out.
1、Brake Shoe
6、Inspect the Brake Shoe for maximum wear, distortion
and crack, in which case it must be replaced.
Maximum wear of Rear Disk Brake Plate is less
than 2.5mm
4.2.2.6 Assembly of Rear Brake System
1Fix Disk Brake Plate onto the Bottom Seat with Special M8 Bolts
(6pcs).
Caution: Grease the bolt with thread glue
