Caution: 1. If the thickness of the disk
brake plate is less than 2.5mm, it must
be replaced.
2. In occasion of crack or
distortion, the disk brake plate must
be replaced.
h) Disk brake plate uses hydraulic pressure of the brake
fluid. Therefore, fuel pipe must be periodically
inspected and replaced.
Inspection Method: Fuel pipe must be replaced when worn
out, cracked or distorted.
4.2.2.2
Disassembly, Inspection and Assembly of Rear Disk Brake
System:
4.2.2.3 Disassembly of Rear Disk Brake System
