Figure 2-18-1
2.1.9 Inspection of lubrication system
1．Lubricant of engine: the vehicle is oiled with lubricant of
APISGSAE10W/40. Others are forbidden.
The capacity is 1.9L after disassembly and assembly.
2、
The capacity is 1.8L when fueling up after drain.
Inspection of oil pump:
Flow of oil pump:
L/min 1500 2000 2500 3000 3500 4000 4500
L/min 2.8 4.0 5.0 6.0 7.1 8.2 9.1
Measure clearance of the top of internal external rotor
Limit value: 0.20mm
