When fastening
Fastening Torque of bolt: 22 N.m -28N.m
2、Mount the Bottom Seat of Rear Disk Brake Plate onto rear
transmission case .Then configure the rear central
transmission shaft, rear transmission case in turn. See
Figure 4-2-15
3、 Mount the Disk Brake Clip onto rear transmission case with
M10×30 Bolts (2pcs)
Fastening Torque: 18 N.m --22 N.m
4、 Mount Fluid Box of Rear Disk Brake onto the Frame with
M Bolt (1pcs).
Fastening Torque: 8 N.m—12N.m
5、Mount Rear Disk Brake Pump onto the Frame with M Bolts (2pcs).
Fastening Torque: 22 N.m—26N.m
6 Fix front wheel hub onto the front wheel shaft with cushion,
open-groove nuts and cotter pins.
Fastening Torque: 50N.m—60N.m
7. Assemble Front Wheel Components onto Front Wheel Hub with
M10 Conical Nuts (GB/T802) (4pcs).
Fastening Torque of Conical Nut: 55 N.m-40N.m
