potential defects.
2. Check Fastening Bolts of all Fuel Pipes for possible
looseness or damage.
3. Check all Fuel Pipes for deterioration, distortion, crack, wear and
other hidden defects.
4. Check the Brake Plate Clip for distortion, crack, and rust and stuck.
5. Inspect the Brake Shoe for wear condition. Brake shoe
must be replaced when worn out. (Figure 4-2-8)
Figure 4-2-8
1) Brake Shoe
6、 Inspect the Brake Shoe for maximum wear, distortion
and crack, in which case it must be replaced.
Maximum wear of Rear Disk Brake Plate is less than
1.5mm
To Next Page
