41

carburetor

serial

number

code

part name and standard

quantity

1

16100-F12-0000

carburetor assembly

1

2

16101-F12-0000

fuel needle part

1

3

16102-F12-0000

column-filled spring

1

4

16103-F12-0000

big diaphragm

1

5

16104-F12-0000

column filler

1

6

16105-F12-0000

diaphragm circlip

1

7

16106-F12-0000

adjusting screw comp, mixing rate

1

8

16107-F12-0000

adjusting screw washer, mixing rate

1

9

16108-F12-0000

adjusting screw o-ring, mixing rate

1

10

16109-F12-0000

main measure hole

1

11

16110-F12-0000

foam pipe

1

12

16111-F12-0000

o-ring, foam pipe

1

13

16112-F12-0000

float pin

1

14

16113-F12-0000

fuel inlet needle valve

1

15

16114-F12-0000

seal gasket, float room

1

16

16115-F12-0000

main spray nozzle

1

17

16116-F12-0000

screw, upper cover

2

18

16117-F12-0000

air measure hole, idle speed

1

19

16118-F12-0000

rubber tube, fuel drain

1

20

16119-F12-0000

screw M4×10

3

21

16120-F12-0000

dense column filler

1

22

16121-F12-0000

measure hole, starting motor

1

23

16122-F12-0000

fuel drain screw

1

24

16123-F12-0000

screw M4×8

3

25

16124-F12-0000

seal gasket, door-hinge room cover

1

26

16125-F12-0000

screw M4×12

1

27

16126-F12-0000

nut M6×0.75

1

28

16127-F12-0000

screw M4×8

1

29

16128-F12-0000

large head screw

1

30

16129-F12-0000

float

1

31

16130-F12-0000

minus pressure tube A

1

32

16131-F12-0000

screw M4×12

2

33

16132-F12-0000

spring cushion

2

34

16133-F12-0000

spring cushion

1

35

16134-F12-0000

fixed clip

1

36

16135-F12-0000

measure hole, idle speed

1

37

16136-F12-0000

PCV valve diaphragm

1

38

16137-F12-0000

clamp sheath, throttle cable

1
