Powtran PI8600 Series User Manual

Section V Parameter Function Table
53
Section V
No reaction
0
No output
Setting frequency
1
0~max frequency
Actual frequency
2
0~max frequency
Actual current
3
0~200%, corresponding parameter: S03 percentage
of output curent
Output voltage
4
0~200%, corresponding parameter: b02、b15 rate
voltage of motor
DC bus voltage
5
0~1000VDC, DC voltage
IGBT temperature
6
0~100.0℃
Output frequency
7
0~200%
Output speed
8
0~max speed
Real torque
9
0~200% torque
10V/20mA
10.0%
20.0%
the corresponded
output frequency
0V/0mA
50.0%
100.0%
0Hz
Voltage/Current
DA1
DA2
This parameter is used for setting upper/lower limitation of DA1/DA2 output signal.
Such as:
If DA1 output 1~5V voltage, setting parameter as: o17＝10.0%, o18＝50.0%
If DA2 output 4~20mA current, setting parameter as: o19＝20.0%, o20＝100.0%
DA1, DA2 Skipping thread:：
Caution: Every terminal has choice of voltage output and current output, the default setting is
voltage output. When the voltage output is needed, please connect JP1/JP2 and
DA1V/DA2V(seeing the panel); When the current output is needed, please connect JP1/JP2
and DA1C/DA2C.
o21
o22
o23
o24
O1output signal select 1
O2output signal select 2
O3output signal select 3
O4output signal select
4
8000
No function
0
-
-
-
-
0
0
1
8
Y
Y
Y
Y
Fault warning
1
Over current inspection
2
Over load inspection
3
Over voltage inspection
4
Less voltage inspection
5
Low load inspection
6
