Powtran PI8600 Series User Manual

Section V Parameter Function Table
52
Section V
frequency*Y2=50.00Hz
y
x
AI1,AI2,AI3
Y1=-100%
X1=0%
X2=100%
100%
Y2=100%
(X2,Y2)
100%
10V
(X1,Y1)
5V
50%
AI2，AI3jump as JP6，JP7，instruction as ：
o12
AI1 input filter time
8000
-
-
-
-
o13
AI2 input filter time
0.00~2.00
s
0.10
Y
o14
AI3 input filter time
0.00~2.00
s
0.10
Y
Filter time constant of analog signal input, that is 0.00~2.00s.If time parameter is set too
long, the changement of setting frequency will be stable, but responsing speed will be slow;If
time parameter is set too short, the changement of setting frequency will not be stable, but
responsing speed will be quick.
o15
o16
DA1 output terminal
DA2 output terminal
No reaction
0
-
-
-
-
Y
Y
Setting frequency
1
Actual frequency
2
Actual current
3
Output voltage
4
DC bus voltge
5
IGBT temperature
6
Output power
7
Output RPM
8
Actual value of torque
9
o17
DA1 adjustment of lower
limit output
0.0~200.0
%
0.0
Y
o18
DA1 adjustment of upper
limit of output
0.0~200.0
%
100.0
Y
o19
DA2 adjustment of lower
limit output
0.0~200.0
%
0.0
Y
o20
DA2 adjustment of upper
limit output
0.0~200.0
%
100.0
Y
Output content
Setting value
Giving Output Singla Range
