Powtran PI8600 Series User Manual

Section V Parameter Function Table
55
Section V
limitation
Arrival of current lower
limitation
31
Time to reach limit time 1
32
Time to reach limit time 2
33
Inverter ready to run
operation
34
Setting
value
Output content
Specification explaination
0
No function
Setting “0”, N output reaction, but inverter can
be controlled by theoretical terminal.
1
Fault Warning
Inverter at fault or after fault with unconfirmed
status.
2
Over current inspeciton
Inverter met fault of over current
3
Over load inspeciton
Inverter met fault of over load of heat protection
4
Over voltage inspeciton
Inverter met fault of over voltage
5
Less voltage inspeciton
Inverter met fault of less voltge
6
Lower load inspection
Inverter met fault of lower load
7
Over heat inspeciton
Inverter met fault of over heat.
8
Running state of command
Inverter is under running state of command
9
Abnormal PID feedback signal
PID feedback signal is abnormal
10
Motor state of REW running
Motor is reverse running
11
Arrival of setting frequency
Arrive at set frequency
12
Arrival of upper frequency
Arrive at upper frequency
13
Arrival of lower frequency
Arrive at lower frequency
14
Arrival of FDT set frequency1
Arrive at frequency 1 FDT set
15
Arrival of FDT set frequency2
Arrive at frequency 2 FDT set
16
Inspection Level Of FDT
Frequency
FDT frequency levels to meet the inspection
conditions,o29~ o31
17
Arrival of preset counting
value
Present counting value arrives at preset counting
value
18
Arrival of counting value
upper limitation
Present counting value arrives at upper
limitation of counting value.
19
Program ruuning one period
completion
Program runs one period to complete.
20
Inspection in speed trick mode
Inverter is under speed trick state, the valid time
is A11
21
No command running state
Inverter is under N command running state
22
REW command of inverter
Inverter is under reverse running command
