2.8.3.1 Analog Control Card Specification
Analog Signal Input
Input mode select
0 - 5Vdc or 0 - 10Vdc or 4 - 20mA select
Accuracy
± 0.2% (full scale)
Resolution
1/4200 max
Input impedance
5M Ohm min ± 5% @ Voltage input mode
250 Ohm ± 5% @ Current input mode
Max. Voltage / Current
Limit
15Vdc max ± 5% @ Voltage input mode
25mA max ± 5% @ Current input mode
Analog Signal Output
Output range
0 - 5Vdc or 0 - 10Vdc or 4 - 20mA select
Accuracy
± 0.2% (full scale)
Resolution
1/4200 max
Digital Signal Input
High voltage level
2.5Vdc - 5.5Vdc max.
Low voltage level
< 1Vdc (Enable)
Max. Voltage Limit.
6Vdc max. ± 10%
Digital Signal Output
Max. output current
5mA / channel max.
Output voltage
0Vdc (Low level)
5Vdc (High level) ± 5% (Enable)
Over voltage protection
6Vdc max. ± 10%
General
Operating Temperature
0℃ - 55℃
Humidity
0 - 90% RH
Connector Type
15 pole D-Type connector (Female)
