AFV-P Series High Performance Programmable AC Power Supply
32
3.5.1.2 Over Current Foldback (OC-FOLD)
At the TESTING subpage 1 (ADVANCED mode), users are allowed to enable the
OC-FOLD mode. Thus when the output current exceeds the set value of maximum
output current, the product can automatically control the output voltage to maintain
the output current at the up limit. For the principle of operation, refer to Subsection
3.5.2.2.
The procedures of enabling the OC-FOLD mode are given as below:
1. Press the item twice to switch the icon status from
OFF to ON.
2. Press the icon to confirm and enable the OC-FOLD mode.
Figure 3.14 Enable the o OC-FOLD mode (ADVANCED mode)
