AFV-P Series High Performance Programmable AC Power Supply
78
The description for the items and the icons at the STEP page are given as follows,
1) : Press to set the start number of the Step Loop, with options
from 1 to 24.
2) : Press to set the end number of the Step Loop, with options from
1 to 24.
3) : Press to set the Step Loop times, with options from 1 to 999.
4) / / : Press to enter into the subpage of the
desired Step.
5) : Show the label number of the current Memory Set.
6) : Press to enable/disable the desired Step.
7) : Press to set the output voltage of the desired Step.
8) : Press to set the output frequency of the desired Step.
9) : Press to set the dwell time of the desired Step.
10) : Press to enter into the TRANSIENT page.
11) : Press to move to the previous page of the STEP page.
12) : Press to move to the next page of STEP page.
