Controls and Instruments 4-47
PA-1628Operator's ManualH3-45 COACH
Pop-up Pictograms
Fire in engine compartment
This pictogram appears if a fire is detected in the engine compartment while the vehicle is
on the road. An audible alarm informs the driver when a fire is detected. In case of fire
detection when parked (parking brake applied, engine running or not), the electric horn is
activated to alert the driver. Refer to "AUTOMATIC FIRE SUPPRESSION SYSTEM
(AFSS)" on page5 in Section 7 Safety Features and Equipment.
WARNING
In case of a fire, stop the vehicle immediately, stop the engine and evacuate the vehicle.
NOTE
It is possible to cancel an alarm while on the road. To do so, stop the vehicle and perform
this ignition switch (key) sequence.
From the ON position, turn to OFF, return to ON and START the vehicle within two
seconds.
To stop the electric horn alarm when parked, cycle the ignition between the ON and OFF
position twice within 3 seconds.
NOTE
To stop the electric horn alarm when parked, cycle the ignition between the on and off
position twice within 3 seconds.
For the location of the extinguisher, refer to "FIRE EXTINGUISHERS " on page4 in
Section 7 Safety Features And Equipment.
