PA-1628Operator's ManualH3-45 COACH
MANUAL LIFT CONTROLS
To Manually Deploy The Platform
1. Fully open sliding door and lift compartment door.
Ensure that there are no obstacles in the path of the
lift.
2. Take the manual backup pump handle attached to the
inner side of the lift compartment door.
3. Engage either keyed release shaft with the pump
handle.
4. Rotate the keyed release shaft ¼-turn (as indicated on
adjacent decal) while lifting stow lock lever
simultaneously.
DECAL
5. Grasp the top edge of the front rollstop with two hands
and pull firmly. The platform moves smoothly after an
initial resistance. Pull platform straight out to the end
of its travel.
