Technical Information 9-7
PA-1628Operator's ManualH3-45 COACH
H3 SERIES WITH WHEELCHAIR LIFT - OVERALL DIMENSIONS
DIMENSIONS AND WEIGHTS H3-41 H3-45
Overall length
(over bumpers)
41’ 0” (12.5m) 45' 0” (13.7m)
Overall width 102" (2.59m)
Overall height
(normal ride height)
146.25" (3.715m)
